Solar Lights
Product Description
Solar Street Light
The series street lights are a solar powered lighting system to provide all roadways with an environmentally friendly and cost-effective street lighting alternative. Many different types of lights are available.Entire pole-mounted system is designed to withstand 150 MPH wind loads. These lights combine the latest technology available to provide years of reliable, low maintenance operation.
Application:
◆All roadways ◆Schools and college campuses ◆Military bases ◆Industrial parks ◆Remote Roadways
Advantage:
1) 100% solar powered 2)No wiring 3)Fast and easy installation 4)No utility bill, save money and energy 5)Low maintenance
6 )Controller has an adjustable timer and low voltage disconnect
7) Intelligent Control for automatically Switching On/Off
8) Environmentally friendly
Specification:
1) Solar Panel: Monocrystallian or Polycrystallian 70-200Wp(can be ordered according to the user's needs),the life-span is more than 20 years;
2) Working voltage 12V (24V) or according to your requirement;
3) Battery: non-maintaining Lead-acid Battery (12 or 24V 70Ah – 200 Ah)
4) Controller: 12V 10Ah Intelligent Controller (single or duel routes output)
5) Luminous flux 7800Lm
6) Lamp: LED Lamp: 20-60W
7) Installation space: 25-28 meters
8) Height: 4.5m – 12 m (or customized)
9) Work Time: Working time≥8h/day,5 days overcast and rainy in succession , it is still normally lighted at night;
10) Operation Temperature Range: -40℃ – 70℃
11) Accessories:Cable,Terminal,etc.
12) We can supply whole set of solar street lights as well as only the solar panel, battery, lamp, controller and installation parts without poles.
____________________________________________________________________________
Product Description
Solar Garden Light
1) Solar Panel: Mono or Polycrystallian 12-200Wp.the life-span is more than 20 years
2) Working voltage: 12V(24V) or according to your requirement;
3) Battery: non-maintaining Lead-acid Battery ( 24V150Ah)
4) Controller: 24V 10Ah Intelligent Controller (single or duel routes output)
5) Light source: LED Lamp 20-60W
6) Installation space: 25-28 meters
7) Height: 4.5m – 12 m (or customized)
8) Work Time: Working time≥8h/day,5 days overcast and rainy in succession, it is still normally lighted at night
9) Operation Temperature Range: -40℃ to 70℃
10) Accessories:Cable,Terminal,etc.
_______________________________________________________________________
Product Description
Wind & Solar Hybrid Street Light
We design two lighting system into one combined system, just in order to guarantee with the power is enough to be charged in the solar battery everyday, if some day there is sunlight but without the wind energy, the solar panel charge the battery. The other way round, if some day there is wind energy but without the sunlight, the wind turbine can charge the power to the battery. When someday both wind & solar energy is enough, both can charge the battery. When the night is coming, the wind turbine is also can continue to work for supply the power to the system, so we sure the system will be popular in the coming future.
Technical Data:
1) Wind Turbine: 12V/400W
2 )Solar Panel: Mono-crystalline solar modules(12V/60W, 2pcs), life time more than 25 years
3) Battery: highly reliable maintenance-free lead-acid storage battery, 2×12V150Ah
4) Control system: special microcomputer intelligent controller (Light & time control, over-charging protection, over-discharging protection)
5) Working voltage:12V DC
6) Light Source:super-bright LED 80W
7) Lighting Time:8-10 hours/day or subject to customer setting based on specific needs, Lasting for 5 to 7 continuous rainy/overcast days
8) Applied temperature:–40℃ to 70℃
9) Material:Metal structure（inside and outside thermal galvanization/plastic coating)
10) Pole height:4.5 to 12m (special requirement is available)
__________________________________________________________________________
Product Description
Solar Lawn Light
1) Powered by solar energy
2) The solar panel converts sunlight into electric energy
3) The electric energy then is charged into the built-in batteries during the day
4) The light sensor turns on the light automatically at night
Product Characteristic:
1) Height: 800MM
2) Poly-crystalline silicon solar panel: 2W/9V
3) Accumulator: 6V/4AH (Lead-acid accumulators)
4) Lamp Sources: white 14-LED (color optional)
5) Control system: solar intelligent exclusive controller
6) Lamp pole:metal
7) Surface Treatment: plastic-spray, anti-/corrosion rust and corrosion proof treatment.
8) Working Time: 8-11H/DAY, normal illumination in consecutive 2-3 rainy days.
9) Suitable for: decoration and illumination for the yard lawn.
